Capabilities & Patented Drive System
the SPIDER ILD02 was developed to handle extreme slopes, inaccessible areas, dangerous terrains, fine turf and extensive mowing on large areas—all in one setup.
The patented drive system enhanced with a skid-steering option enables mowing in all directions and extreme climbing ability up to 55 degrees*.
*OFFICIAL CERTIFICATION DOCUMENTATION AVAILABLE UPON REQUEST.
Key features include:
-
All-Direction Mowing: Patented drive system with skid-steering allows easy navigation around obstacles and challenging terrains.
-
Exceptional Cutting Efficiency: Delivers high-quality mulching with a cutting width of 48.5 inches.
-
Cost-Efficient: Lowers operating costs with reduced environmental impact and the need for fewer workers.
-
Compact and Versatile Design: Ideal for both professional landscaping and demanding municipal use.
-
Gentle on Terrain: A patented stabilizing winch ensures safety without damaging the ground surface.
Design & Capabilities
All-Aluminum Chassis
Lightweight and corrosion-resistant for long-lasting durability.
Hardox Alloy Blades
Durable for quality mulching.
Patented Drive System
All-directional mowing for maximum maneuverability.
Patented Winch System
For increased accessibility on steep slopes.
Structure & Performance
The SPIDER ILD02’s unique steering system, lightweight structure and low center of gravity eliminate the risk of erosion on steep slopes. The four-blade mowing mechanism ensures a perfect cut and can easily handle unmaintained areas.
The ILD02 uses a high performance Kawasaki engine, designed to cut through dense growth on steep slopes and hillsides.
This steep-slope mower’s productivity is comparable to that of 15 workers using brush cutters. More than 10 years of continuous product development has resulted in a highly reliable product.
ONE SPIDER CAN YIELD BIG RESULTS
Overcome Labor-Shortage Challenges
At Spider Mower USA, we understand the impact of labor shortages on the landscaping industry. That’s why we provide a reliable solution that ensures you can get the work done, even during challenging times of labor shortages.
With our innovative technology and all-in-one lawn mowing solution, you can overcome the limitations posed by labor shortages with confidence. Say goodbye to productivity setbacks and hello to a reliable way to get the job done, regardless of labor availability.
Technical Specifications
Engine
Kawasaki FS691V
Performance
24 HP / 17.9kW Gross HP SAE J1940
Displacement
776 cc
Fuel Tank
4.2 gal.
Fuel
Unleaded Petrol
Transmission
Hydrostatic
Oil Tank
2.4 gal.
Speed
0 – 5 mph
Drive
360°, 4-wheel drive
Skid-Steering
Yes
Tire Type
16 × 6.50–8
Cutting Width
48.5 in. (4 blades)
Cutting Height
3.5 – 5.5 in. / 2.8 – 4.7 in.
Clutch
Electromagnetic
Productivity
up to 1.73 acres/hr.
Fuel Consumption
.95 gal/hr.
Climbing Ability
Up to 55º
Hydraulic Winch
Yes
Dimensions
65 × 56 × 36 in.
Gross Weight
853 lbs.
Application
SPIDER IS
"America's Best RC Slope Mower Warranty"
When it comes to outdoor power equipment, Spider Mower USA offers America’s Best Warranty. No other company offers a two-year or 800-hour (whichever comes first) manufacturer’s warranty and a three-year Kawasaki/Honda engine warranty.
Some companies offer warranties that are only valid for a limited time and only apply within the state it was purchased in. Our warranty extends the same for all 50 states, U.S. territories and countries—meaning, you can take our mower anywhere and still be covered by our warranty. All warranties are against manufacturer’s defect, not including wear and tear parts.
